Air Heating Elements

Air Heating Elements

Air heating elements can obtain higher operating temperature under lower operating pressure. The equipment is small in size, flexible in installation and large in power. Fast thermal response, high temperature control accuracy, and high comprehensive thermal efficiency.

Description

Technical characteristics of air heating elements:

1. It can obtain higher working temperature under lower operating pressure.

2. The thermal efficiency of air heating elementsr is high, up to 95%, and the temperature control accuracy can reach ±1℃.

3. The equipment is small in size, flexible in installation and large in power.

4. Fast thermal response, high temperature control accuracy, and high comprehensive thermal efficiency.

5. Air heating elements have a wide application range and strong adaptability. They can be used in explosion-proof or ordinary occasions. Its explosion-proof grade can reach B and C grades, and its pressure resistance can be 20Mpa. And the cylinder can be installed vertically or horizontally according to user needs.

6. High heating temperature: The design maximum working temperature can reach 650℃, which is not available in general heat exchangers.

7. The air heating elements have a long life and high reliability. It is made of special electric heating materials, and the design power load is more conservative.

Technical Parameters

Pipe diameter: Φ6mm-φ67mm

Voltage: 110V-415V

Heating power: 1KW-120KW

Watt density: 30W/square centimeter

Wattage tolerance: +5%

Length tolerance: ±1.5%

Resistance wire: nickel-chromium resistance wire (Ni80Cr20)

Sheath material: copper, titanium, stainless steel, Incoloy 800, Incoloy 840

Surface treatment: polishing, coating, electroplating
