Ptfe Heaters

ptfe heaters

Excellent corrosion resistance.

features

Ptfe Heaters

PTFE casing 304 stainless steel elements are inert to up to 212°F(100°C) in most solutions.

Low power density design 10 watts per square inch (1.5 w/cm).

4 ft (1.2 m) continuous fluoropolymer (PTFE) cable connecting steam resistant terminal housing and 3 ft (1.9 m) flexible PVC liquid sealing conduit.

Ground internal metal elements and built-in heat protectors.

Recoverable type P3 j thermocouple standard.

Anti-corrosion heating tube is a new type of electric heating tube which is resistant to strong corrosion. It is used for heating all kinds of corrosive liquids.

Ptfe Heaters

It has good aging resistance and good winding performance, and adopts low surface load design.

The connector is fully enclosed for acid and alkali protection, and the safety protection system for non-heating section and overheating is completely customized according to customers' requirements.

Good to ensure that the heater is not easy to burn out, long service life, full sealing, no corrosion, no leakage, with grounding protection, safe and reliable.

Applicable temperature below 110°C.

(heat in very thick liquid, must be configured with stirring)

Mosquito-repellent incense type - anticorrosive teflon electric heating tube has the advantages of high thermal efficiency, energy saving, high cost performance, can design a variety of structural forms, such as spiral, L, U, W, mosquito-repellent incense type, combined type and so on.

It has been recognized by many listed companies and has been a long-term supplier of its mosquito-repellent incense teflon electric heaters.

We can undertake non-standard products, in voltage, power, specifications and product shape, as well as wiring mode, according to the customer's needs to let engineers design, welcome to map to sample custom production.

Ptfe Heaters

Anti-corrosion heating tube products:

1) the anti-corrosion heating tube is made of high quality stainless steel (sus316 or sus304) inner core of the electric heat tube, and is made of teflon tube (PTFE), which has strong corrosion resistance and is suitable for all kinds of corrosive liquid heating.

2) the heater is designed with low surface power (1.5w/c㎡) to ensure the service life of the product.

3) the installation location of the electric heater should pay attention to prevent the solid in solution from being deposited on the surface of the electric heater, or if the liquid is too thick and the liquid level is too low, it will burn out PTFE (iron fluoride) due to poor s
