What are the testing standards for electric heating tubes?

As consumers, we all want to buy things with low prices and good quality, and the same goes for buying electric heating tubes. But the electric heating tube is a non-standard customized product, what is the testing standard for the electric heating tube?

One: Appearance check

1) The surface is smooth, without uneven holes.

2) No barbs

3) The cutting mouth is flat and smooth.

4) Even color

5) The welding port is tight, without hollowing out,

Two: internal design

1) Whether the power design is reasonable; to see whether the power and size are reasonable, please refer to:

2) Whether the material selection is appropriate; to see whether the material is appropriate, reference basis: a selection of the shell material of the electric heating tube

Three: Whether it meets the national standard: Industrial electric heating tube standard: JB/T GB2379-1993 Metal tubular electric heating element

1) Voltage: Is it customized according to requirements

2) Rated power error value: under full heating conditions,

     a. For components with rated power less than or equal to 100W: ±10%

     b. For components with rated power greater than 100W: +5% to -10% or 10W, whichever is greater.

3) Insulation resistance value: cold resistance not less than 50 megohms during factory inspection; insulation resistance not less than 1 megohm after long-term storage or use;

4) Leakage current: cold leakage current and leakage current after water pressure and sealing test should not exceed 0.5mA

5) High voltage strength: 1500V/Min, no breakdown

Meet the requirements of the above electrical parameters.

The above three points are what the testing standards of electric heating tubes are. Therefore, you still have to go to regular manufacturers to buy electric heating tubes. Our company strictly produces products in accordance with national production standards. The factory inspection is strictly controlled. Only in this way can we produce electric heating tubes that satisfy customers and rest assured. Heat the product.

Friends who want to know more detailed testing standards for electric heating tubes can contact us.
