Thermocouple Types

Advantages of thermocouple

1. Simple assembly and convenient replacement;

2. Compression spring type temperature sensing element, good seismic performance;

3. High measurement accuracy;

4. Large measuring range (-200℃～1300℃, under special circumstances -270℃～2800℃);

5. Fast thermal response time;

6. High mechanical strength and good pressure resistance;

7. High-temperature resistance can reach 2800 degrees;

8. Long service life.

How thermocouple works

Two conductors with different components (called thermocouple wires or thermoelectrodes) are connected at both ends to form a loop,

When the temperature of the two junctions is different, an electromotive force will be generated in the loop. This phenomenon is called the thermoelectric effect, and this electromotive force is called the thermoelectric force. Thermocouples use this principle for temperature measurement. The end directly used to measure the temperature of the medium is called the working end (also called the measuring end), and the other end is called the cold end (also called the compensation end); the cold end and the display When the instrument or supporting instrument is connected, the display instrument will point out the thermoelectric potential generated by the thermocouple.

thermocouple types

Seven standardized thermocouples, S, B, E, K, R, J, T.
