Flexible Tubular Heater

Flexible tubular heaters make the heating of complex platens, shapes, and machines, possible. Flexible tubular heaters are completely flexible, and may be shaped at will. Around pipes, along platen paths, and other challenging shapes.
Excellent replacements for traditional tubular heaters, which are not flexible and most can be custom made in most cases.

Benefits: Flexible Tubular Heater

Easy installation with a uniform finish
Can be formed by hand
Stored in a straight condition to save storage space
No special installation tools required
Up to 75% sheath contact with round and square TS heaters
Rapid heat-up times
Minimal temperature difference between heater sheath and heated tool
3-dimensional groove geometry possible
Industry’s smallest bending radius
Flexibility enables heat to be located where it is needed, an improvement over cartridge heaters
Reduced energy costs, so tool mass can be reduced
Technical Specifications:
6.5, 8.0, 8.5, and 10 mm Diameters
30 mm unheated zones at each end
Wattage tolerance +/- 10%
Diameter tolerance +/- 0.1 mm

Flexible Tubular Heater

Applications: Flexible Tubular Heater
Plastic Injection Molding
Rubber Molding
Packaging
Plastic Welding
Plate Heating
Specialty heated tools
Food Processing Market

The Flexible Tubular heaters compress into the groove and provide excellent heat transfer. Straight lengths available Ex-Stock eliminate costly downtime associated with waiting for custom bent tubular heaters. Engineered with a robust design incorporating greater thermal mass, our Flexible Tubular Heater is user-formable with a flexible solid casing that stays in the groove, yet is easy to install.
