Our company develops various flexible ceramic pad heaters. The flexible ceramic pad heater has a very wide range of uses, with good quality and low price. Ceramic electric heaters have the characteristics of a wide application range, fast heating speed, high and remarkable heat utilization rate, low labor intensity, and convenient operation.
Our company develops various flexible ceramic pad heaters. The flexible ceramic pad heater has a very wide range of uses, with good quality and low price. Ceramic electric heaters have the characteristics of a wide application range, fast heating speed, high and remarkable heat utilization rate, low labor intensity, and convenient operation.
Features
1. The flexible ceramic pad heater has winding properties. For example, when heating containers or pipes, it can be bent into an arc or circle to coat the surface for heating. For heating large workpieces, partial coatings can be adopted, and large-area workpieces can be flat. Cover the form. In addition, it is suitable for heating equipment of various geometric shapes.
2. High working temperature, fast heating, high thermal efficiency, uniform heating, and automatic control can be realized.
3. High mechanical strength, good thermal insulation performance, and large contact surface with the heated object.
4. It is convenient to install and maintain, and the use cost is low. Even if the internal heating material is damaged, the external ceramic components can still be reused.
Technical index:
1. Dielectric strength: 2000V/1 minute
2. Thermal insulation resistance: >5MΩ
3. Working temperature: 1050℃
installation tips
1. According to the size of the equipment, single or multiple components can be evenly arranged. The fixing method during installation can be tied with stainless steel wire or bent into a fastening ring, and then fastened in series with screws.
2. From temperature requirements and considerations, the heater should be covered with 6-8cm insulation material and a temperature controller.
3. It is not allowed to overlap when using a flexible ceramic pad heater, so as not to form an overheated zone and affect life. Be careful not to break the porcelain, so as not to expose the electric heating material and affect safety.
4. The heated workpiece must be reliably grounded. The working voltage shall not exceed 1.05 times the customer-rated voltage.
Our company provides you with a variety of models and specifications, each of which has its own characteristics and performance. Such as LCD type flexible ceramic pad heater, SCD type The flexible ceramic pad heater, NJ type The flexible ceramic pad heater, and so on. Generally, users are required to choose according to the shape, thickness, and required temperature of the heated equipment.
